APC Smart-UPS 2200VA LCD RM 2U (SMT2200RMI2U) – Best Rack Mount UPS for Servers in Pakistan
The APC Smart-UPS 2200VA LCD RM 2U 230V (SMT2200RMI2U) is Pakistan’s most trusted 2U rack mount UPS for IT professionals, data centres, and businesses that cannot afford downtime. Delivering 1980 Watts / 2200VA of pure sine wave output in a compact rackmount form factor, this APC UPS protects your servers, switches, routers, firewalls, and network equipment from power outages, voltage surges, and grid fluctuations across Lahore, Karachi, Islamabad, and all over Pakistan.
Why Choose APC Smart UPS 2200VA (SMT2200RMI2U)?
- Line Interactive Topology with Automatic Voltage Regulation (AVR) corrects high and low voltage without switching to battery — extending battery life and maximising uptime.
- Pure Sine Wave Output ensures complete compatibility with PFC (Power Factor Corrected) servers and sensitive electronics.
- Fast 4ms Transfer Time (8ms maximum) delivers near-seamless switchover to battery backup during power failures.
- 2U Rack Mount Form Factor fits standard 19-inch server racks with the included mounting hardware and support rails.
- Multi-Function LCD Display provides real-time load, battery level, input/output voltage, and fault indicators — plus On Line, On Battery, Replace Battery & Overload LEDs.
- SmartSlot Interface supports optional network management cards (AP9631 / AP9640) for remote monitoring, alerts, and shutdown.
- USB Connectivity for seamless integration with PowerChute Business Edition software.
- 375 Joule Surge Protection guards your equipment against harmful electrical spikes and lightning surges.
- Maintenance-Free Sealed Lead-Acid Battery (leak-proof) with 169W charge power and expected life of 3–5 years.
- 3-Year Repair-or-Replace Warranty (2 years on battery) — genuine Schneider Electric backing.
APC SMT2200RMI2U Technical Specifications
- Output Power: 1980W / 2200VA
- Output Voltage: 220V / 230V / 240V (configurable)
- Waveform Type: Pure Sine Wave
- Topology: Line Interactive
- Output Frequency: 50 / 60 Hz +/- 3 Hz
- Transfer Time: 4ms typical, 8ms maximum
- Input Voltage Range (main operations): 160V – 286V
- Input Voltage Adjustable Range: 151V – 302V
- Input Frequency: 50 / 60 Hz +/- 3 Hz (auto sensing)
- Battery Type: Maintenance-Free Sealed Lead-Acid (leak-proof)
- Recharge Time: 3 hours to 90% capacity
- Expected Battery Life: 3 – 5 years
- Battery Charge Power: 169 Watts
- Replacement Battery Cartridge: APC RBC43
- Interface Ports: USB, SmartSlot (1)
- Control Panel: Multi-function LCD + LED status indicators
- Surge Energy Rating: 375 Joules
- Audible Noise (at 1 metre): 55 dBA
- Online Thermal Dissipation: 215 BTU/hr
- Form Factor: 2U Rack Mount (fits 19-inch racks)
- Dimensions (H × W × D): 86 × 480 × 683 mm
- Net Weight: 42.31 kg
- Operating Temperature: 0 – 40 °C
- Operating Humidity: 0 – 95%
- Operating Elevation: 0 – 3000 metres
- Compliance / Approvals: CE, EAC, EN 60950, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEE
- RoHS: Compliant
- Warranty: 3 Years (Battery 2 Years)
Ideal Applications for APC Smart-UPS 2200VA in Pakistan
- Server rooms & on-premise data centres
- Rack-mounted servers (Dell, HP, Lenovo, Supermicro)
- Network closets — routers, managed switches, firewalls
- Storage systems (NAS/SAN) & backup appliances
- Telecom, ISP & last-mile infrastructure
- Bank branches, financial terminals & ATM backup
- Medical imaging & diagnostic equipment
- CCTV, NVR/DVR & enterprise security systems
- Point-of-Sale (POS) & retail infrastructure
What’s Included in the Box
- APC Smart-UPS 2200VA Unit (SMT2200RMI2U)
- Rack Mounting Hardware
- Rack Mounting Support Rails
- Software CD with PowerChute Business Edition
- Documentation CD & Installation Guide
- Smart UPS Signalling RS-232 Cable
- USB Cable
- User Manual & Warranty Card
APC Smart UPS 2200VA Price in Pakistan – Link Power Engineerings
At Link Power Engineerings, we offer the best APC Smart UPS 2200VA price in Pakistan on 100% genuine Schneider Electric units — every unit shipped with verified serial numbers, original manufacturer warranty, and professional rack installation available across Lahore, Karachi, and Islamabad. Whether you need a single unit for your server room or bulk quantities for a full data centre deployment, our Schneider-certified engineering team will help you specify, install, and maintain the right solution.
Call +92 327 1000669, WhatsApp our team, or use the Contact Us button above for a same-day quote, load calculation, and delivery timeline.
