APC Smart-UPS RC 1000VA 230V (SRC1000I) – Double Conversion Online UPS with Battery

APC Smart-UPS RC 1000VA 230V (SRC1000I) – Compact Online UPS for Critical Loads in Pakistan

The APC Smart-UPS RC 1000VA 230V (SRC1000I) is Schneider Electric’s compact double-conversion online UPS — engineered to deliver the cleanest, most reliable power protection available for individual mission-critical devices. Delivering 800 Watts / 1.0 kVA with zero transfer time, 88% efficiency at full load, LED status console, and built-in bypass, this UPS is the entry point to APC’s Online UPS technology. Perfect for single critical servers, medical imaging devices, ATM terminals, high-end workstations, and sensitive laboratory equipment across Lahore, Karachi, Islamabad, and Pakistan-wide. Sourced, installed, and supported by Link Power Engineerings, Pakistan’s certified APC power partner.

Why Choose APC Smart-UPS RC 1000VA (SRC1000I)?

• Double Conversion Online Topology — the highest-grade UPS protection available. Your load runs continuously on inverter power, completely isolated from grid disturbances.
• Zero Transfer Time — unlike Line Interactive UPS models (2–8ms transfer), no switchover gap when grid power fails. Perfect for equipment that reboots on brief interruptions.
• Pure Sine Wave Output with less than 2% distortion — clean enough for medical imaging, financial terminals, and scientific instruments.
• 88% Efficiency at Full Load — reduces operating cost and cooling load compared to older online UPS models.
• 259 VAH Internal Battery — larger than most 1kVA online UPS models in its class, delivering longer runtime out of the box.
• 86W Battery Charge Power — fast 3-hour recharge to full capacity after outages.
• LED Status Display with load and battery bar-graphs plus On Line, On Battery, Replace Battery, Overload, and Bypass indicators.
• Wide Input Voltage Range (100 – 280V adjustable, 160 – 280V main operations) — tolerates severe voltage sags without switching to battery, extending battery life in Pakistan’s variable-grid conditions.
• 420 Joule Surge Protection plus full-time multi-pole noise filtering — meets UL 1449 standards.
• RJ-45 Data Line Protection — safeguards modem, fax, and network connections against surge damage.
• Emergency Power Off (EPO) support — required for many data centre and facility installations.
• SmartSlot Interface supports optional AP9631 / AP9640 network management cards for remote SNMP monitoring, email alerts, and PowerChute Network Shutdown.
• DB-9 RS-232 Interface — legacy management system compatibility.
• Quiet Operation at 50 dBA — comfortable for office and clinical environments.
• Load Crest Factor 3:1 — handles high inrush loads without derating.
• 2-Year Repair-or-Replace Warranty — with local UPS repair service in Lahore from Schneider-certified engineers for out-of-warranty support.

APC SRC1000I Technical Specifications

• Output Power: 800W / 1.0 kVA
• Output Voltage: 230V nominal, 220V / 240V configurable
• Waveform Type: Pure Sine Wave
• Topology: Double Conversion Online
• Efficiency at Full Load: 88%
• Output Voltage Distortion: Less than 2%
• Output Frequency: 50 / 60 Hz ± 3 Hz Sync to Mains
• Load Crest Factor: 3 : 1
• Bypass: Built-in Bypass
• Input Voltage Range (main operations): 160V – 280V
• Input Voltage Adjustable Range: 100V – 280V
• Input Frequency: 47 – 63 Hz
• Number of Power Cords: 1
• Battery Type: Maintenance-Free Sealed Lead-Acid
• Included Battery Modules: 1 (internal)
• Battery Volt-Amp-Hour Capacity: 259 VAH
• Battery Charge Power: 86 Watts
• Typical Recharge Time: 3 hours
• Expected Battery Life: 3 – 5 years
• Interface Ports: DB-9 RS-232, SmartSlot
• Control Panel: LED status display with load & battery bar-graphs, On Line / On Battery / Replace Battery / Overload / Bypass indicators
• Emergency Power Off (EPO): Yes
• Available SmartSlot Interfaces: 1
• Surge Energy Rating: 420 Joules
• Data Line Protection: RJ-45 Modem/Fax (four-wire dual line)
• Filtering: Full-time multi-pole noise filtering (meets UL 1449)
• Dimensions (H × W × D): 257 × 166 × 420 mm
• Net Weight: 14.82 kg
• Color: Black
• Operating Temperature: 0 – 40 °C
• Operating Humidity: 0 – 95%
• Audible Noise (at 1 metre): 50 dBA
• Online Thermal Dissipation: 652 BTU/hr
• Compliance / Approvals: EN 60950, EN/IEC 60950-1, EN/IEC 62040-1, EN/IEC 62040-2
• RoHS: Compliant
• Warranty: 2 Years Repair or Replace

Ideal Applications for APC Smart-UPS RC 1000VA in Pakistan

• Single critical business servers & NAS storage
• Medical devices — ultrasound consoles, patient monitors, diagnostic terminals
• ATM machines & card processing terminals
• Financial trading workstations & broker terminals
• Laboratory equipment — GC/HPLC controllers, ELISA readers, microscopy stations
• High-end audio/video editing workstations
• Industrial PLC/HMI controllers
• Bank branch teller terminals & kiosks
• Telecom edge equipment requiring zero downtime

What’s Included in the Box

• APC Smart-UPS RC 1000VA Unit (SRC1000I) — with internal battery installed
• CD with PowerChute Software
• Smart UPS Signalling RS-232 Cable
• User Manual & Warranty Card

APC Online UPS Family — Scaling Up as Your Load Grows

APC’s Smart-UPS RC (Online) family scales from single-device protection to full data-centre installations. Beyond this 1 kVA / 800W SRC1000I entry point, our range continues to enterprise capacity. For full data-centre deployment requiring 9 kW of enterprise-grade protection, the APC Smart-UPS RC 10000VA (SRC10KUXI) is a 10 kVA online UPS with scalable runtime via external battery cabinets. All units share the same double-conversion topology and zero transfer time — the difference is capacity and battery configuration.

Considering Line Interactive Instead? Save with SMT

If your load is less critical and can tolerate a brief 2–8ms transfer, you may save 30–40% by choosing a Line Interactive UPS. The APC Smart-UPS 1500VA with SmartConnect (SMT1500) tower offers 1000W of Line Interactive protection with remote cloud monitoring at a lower price point. For rack deployments, the APC Smart-UPS 2200VA Rack Mount (SMT2200RMI2U) delivers 1980W with SmartSlot and enterprise features. Our engineering team will help you decide based on your equipment sensitivity, budget, and criticality tolerance.

Professional Installation & Support in Pakistan

Every APC Online UPS from Link Power Engineerings ships with the option of professional UPS installation service in Lahore — including site power quality survey, load calculation, EPO wiring, PowerChute software configuration, and full commissioning by Schneider Electric certified engineers. For enterprise clients, our AMC service includes quarterly battery health checks, firmware updates, and priority emergency UPS repair & onsite response.

APC Smart UPS RC 1000VA Price in Pakistan – Link Power Engineerings

At Link Power Engineerings, we offer competitive APC Smart UPS RC 1000VA price in Pakistan on 100% genuine Schneider Electric units — every unit shipped with verified serial numbers, original manufacturer warranty, and expert installation available across Lahore, Karachi, and Islamabad.

Call +92 327 1000669, WhatsApp our team, or use the Contact Us button above for a same-day quote and delivery timeline.
